| Model | TEW-45 | TEW-50 | TEW-65 | TEW-80 |
| Material | Carbon Fibre-Toray T700 | Carbon Fibre-Toray T700 | Carbon Fibre-Toray T700 | Carbon Fibre-Toray T700 |
| Size | 700C | 700C | 700C | 700C |
| Appearance | UD | UD | UD | UD |
| Finish | Matte/Glossy | Matte/Glossy | Matte/Glossy | Matte/Glossy |
| Rim depth | 45mm | 50mm | 65mm | 80mm |
| Rim width | 25mm(U shape) | 25mm(U shape) | 25mm(U shape) | 25mm(U shape) |
| Brake Line Width | Disc no Braking Surface | Disc no Braking Surface | Disc no Braking Surface | Disc no Braking Surface |
| Rim type | Tubeless | Tubeless | Tubeless | Tubeless |
| Wheel Out Diameter | 633mm | 633mm | 633mm | 633mm |
| ERD | 550mm | 540mm | 510mm | 480mm |
| Assembly Hole Dia | 7.5mm | 7.5mm | 7.5mm | 7.5mm |
| Spoke Hole Dia | 4.5mm | 4.5mm | 4.5mm | 4.5mm |
| Valve Hole Dia | 6.5mm | 6.5mm | 6.5mm | 6.5mm |
| Flatness | <0.2mm | <0.2mm | <0.2mm | <0.2mm |
| Roundness | <0.5mm | <0.5mm | <0.5mm | <0.5mm |
| Maximum Tire Pressure | 120psi | 120psi | 120psi | 120psi |
| Spoke Tension Front | 100-130kg | 100-130kg | 100-130kg | 100-130kg |
| Spoke Tension Rear | 100-130kg (Non-Drive Side) 150-180kg(Drive Side) | 100-130kg (Non-Drive Side) 150-180kg(Drive Side) | 100-130kg (Non-Drive Side) 150-180kg(Drive Side) | 100-130kg (Non-Drive Side) 150-180kg(Drive Side) |
| Yaw | 0.2mm | 0.2mm | 0.2mm | 0.2mm |
| Weight | 1700+/-20g | 1760+/-20g | 1850+/-20g | 1980+/-20g |
| Maximum Weight | 200kg*2 (front and rear) | 200kg*2 (front and rear) | 200kg*2 (front and rear) | 200kg*2 (front and rear) |
| Hub | Novatec 041/042 | Novatec 041/042 | Novatec 041/042 | Novatec 041/042 |
| Spoke Holes | 24-24H or 28/28H | 24-24H or 28/28H | 24-24H or 28/28H | 24-24H or 28/28H |
| Spoke Color | CN Round Spokes (Black) | CN 494 (Black) | CN 494 (Black) | CN 494 (Black) |
| Nipple Color | Alloy CN nipples (Black) | Alloy CN nipples (Black) | Alloy CN nipples (Black) | Alloy CN nipples (Black) |
| Quick Release(skewers): | Inclued(Balck) | Inclued(Balck) | Inclued(Balck) | Inclued(Balck) |
| Fit Frame | For road bike | For road bike | For road bike | For road bike |
| Cassette Body | (fit for shiman0 8/9/10/11/12 speed or XDR 12) | (fit for shiman0 8/9/10/11/12 speed or XDR 12) | (fit for shiman0 8/9/10/11/12 speed or XDR 12) | (fit for shiman0 8/9/10/11/12 speed or XDR 12) |
| Warranty | 2 year | 2 year | 2 year | 2 year |
| Quality Control | All pass EN standard test | All pass EN standard test | All pass EN standard test | All pass EN standard test |
